Oversimplified guide into snapshots on the btrfs filesystem
Friday afternoon. You’re trying out a script that you wrote to mass-rename and move some files around. You finish the script and test it out.
Oops.
All the files now have all the wrong names, and some have been randomly moved 10 folders deep. It’s a mess.
And you didn’t make a backup of your files right before this step because you thought that you wouldn’t need it. It’s just a simple script, after all…
If you’ve found yourself in a similar situation and want to know how to avoid problems in the future, then this article is for you
btrfs: overview
btrfs
(butter-fs, bee-tee-arr-eff-ess) is a modern filesystem present in the Linux
kernel that has a lot of great features:
- different RAID levels: RAID0, RAID1, RAID10…
- data integrity guarantees
- snapshots
- and many more!
btrfs
does have some downsides and has had its fair share of issues and
controversy in the past, but at least during the last couple of years it’s been
fine in my simple RAID1 + snapshots use cases.
In this post, we’ll focus on the snapshots feature that btrfs
offers.
If you’re not sure what snapshots are, then you can think of them as a still image of the state of your filesystem at a certain point in time. You can create a snapshot of the filesystem, delete all your files, and still be able to get your files back just like you left them.
If you’re a developer who has used git
and doesn’t mind oversimplified (and
probably incorrect) explanations: you can think of snapshots like git
commits.
You can take snapshots (commit), roll back to a previous snapshot (reset/revert)
or view the contents of a previous snapshot (checkout commit).
One thing to keep in mind with snapshots is that they will take up space, especially if you make a lot of them and move files around a lot.
There are many tools available to manage btrfs
snapshots. The one I’ve opted
for is snapper
.
Snapper quick-start
Here’s a quick guide on how to get started with snapshotting your btrfs
filesystem. The example is based on a system with a btrfs
filesystem mounted
on /home
- Install
snapper
- Ubuntu/Debian:
sudo apt install snapper
- Fedora:
sudo dnf install snapper
- Ubuntu/Debian:
- Setup the configuration:
sudo snapper -c home create-config /home
/etc/snapper/configs
now has a text file namedhome
that you can configure to your liking. My personal recommendation is to use theTIMELINE
snapshots configuration to configure the maximum number of hourly and daily snapshots.snapper
ships with two systemd timers that automatically take new snapshots and remove old ones. Make sure that they are enabled:sudo systemctl enable --now snapper-timeline.timer snapper-cleanup.timer
- After a while, you should be able to see snapshots appear in the output of
sudo snapper list
. - If you want to browse the files for the old snapshots, go to
/home/.snapshots
.
Example output of sudo snapper list
on my machine:
> sudo snapper list
# | Type | Pre # | Date | User | Cleanup | Description | Userdata
------+--------+-------+--------------------------+------+----------+-------------+---------
0 | single | | | root | | current |
1 | single | | K 16 märts 2022 08:12:01 | root | timeline | |
242 | single | | K 16 märts 2022 13:00:16 | root | timeline | |
302 | single | | K 16 märts 2022 14:00:05 | root | timeline | |
362 | single | | K 16 märts 2022 15:00:10 | root | timeline | |
422 | single | | K 16 märts 2022 16:00:19 | root | timeline | |
461 | single | | K 16 märts 2022 17:20:29 | root | timeline | |
501 | single | | K 16 märts 2022 18:00:02 | root | timeline | |
...
That’s it!
Snapper tech tips
If you’re new to snapshots, then I recommend keeping an eye on your disk usage
and tuning the snapper
timeline related configurations to your liking. For my
/home
folder, my configuration looks like this:
# create hourly snapshots
TIMELINE_CREATE="yes"
# cleanup hourly snapshots after some time
TIMELINE_CLEANUP="yes"
# limits for timeline cleanup
TIMELINE_MIN_AGE="300"
TIMELINE_LIMIT_HOURLY="48"
TIMELINE_LIMIT_DAILY="7"
TIMELINE_LIMIT_WEEKLY="0"
TIMELINE_LIMIT_MONTHLY="0"
TIMELINE_LIMIT_YEARLY="0"
With this configuration, I can undo my screw-ups for up to 7 days, with more granular control for changes done within the last 48 hours.
If you have data that changes more often than other data on the same filesystem,
then I recommend utilizing btrfs
subvolumes and creating separate snapper
configurations for each.
For example: a folder containing gigabytes of cat pictures is unlikely to change all that often, so a longer snapshot retention policy of 24 hourly/30 daily snapshots is a sensible one.
However, the contents of my downloads
folder changes more frequently and may
contain bigger files that I need temporarily, such as the ISO file for the
latest Fedora/Debian release. In a situation like that, having a 6 hourly/7
daily snapshots policy will make more sense, especially if I don’t want to run
out of space due to excessive number of snapshots taken for that filesystem.
Further reading: ZFS snapshots
ZFS
is a fantastic filesystem that offers many of
the features boasted by btrfs
, and some that btrfs
doesn’t have. ZFS also
supports snapshots. To set up automatic snapshot creation and pruning on ZFS,
I can recommend sanoid
.
